Product Type

PC-3000 Mobile PRO

PC-3000 Mobile

DATA EXTRACTION FROM MOBILE DEVICES

FOR LAW ENFORCEMENT & CERTIFIED DIGITAL FORENSICS AGENCIES ONLY



DO YOU HAVE THE UNSOLVED CASES WITH MOBILE DEVICES?



Today, we cannot imagine our lives without portable devices. New models pop up every day: we use them to communicate, to study, to work. But so do the criminals! The complexity of modern mobile devices may bring you an unaccounted number of challenges during evidence recovery. That is why it is so important to have at your disposal every forensic data recovery tool that can help you with the investigations!

PC-3000 Mobile





HARDWARE-SOFTWARE SYSTEM TO RECOVER DATA FROM:

  • Smartphones (Mobile Phones)
  • Tablets



SEVERAL WAYS OF ACCESSING DATA

ACE Lab know-how methods to recover data

The PC-3000 Mobile PRO includes a specialized set of ACE Lab unique methods and utilities meant for low-level access to mobile devices with the help of a USB cable to recover data in the most complicated cases.

Work with damaged mobile devices

Get the data even if the mobile device is damaged! Minimum operating condition of the mobile device is required


WORK WITH DAMAGED DEVICES



The PC-3000 Mobile PRO specialized modes let you deal with damaged mobile devices. In addition, it has the features to deeply analyze and recover logically damaged Files Systems: FAT12/16/32, NTFS, Ext2/3/4, HFS+, exFAT, F2FS, etc.

PC-3000 Mobile

RECOVER DATA WITH LOW-LEVEL



Retrieve data through the standard ports of the devices with the help of low-level protocols and software methods that are themselves the result of many years of research and development.

PC-3000 Mobile

ANALYZE CONTENT



Extract evidence with the PC-3000 Mobile PRO set of analytical functions, tools for forensic analysis, and content parsing modules! Get the access to the phone contacts, calendar, SMS, WhatsApp, mediafiles, general phone information, the list of Wi-Fi networks, and accounts information. The Android version does not matter! The main task of the PC-3000 Mobile PRO is to get access to the data other than parsing. So, after you have received access to the data with the PC-3000 Mobile PRO, you can work with this information using other third party tools.

PC-3000 Mobile

EXPORT DATA & GET THE REPORTS



After you get the data, you may export it to the formatted report, one of the transport formats, or files. It is also possible to generate data exports compatible with other data analysis tools that you may have in your lab to continue the investigation.

PC-3000 Mobile



Technical features




A SPECIAL SD/MMC ADAPTER

With the special SD/MMC adapter, you can deal with the following types of MMC and MCP memory chips:

  • eMMC 153/169: 11.5 x 13, 10 x 11, 9 x 11, 14 x 18, 12 x 18, 12 x 16, 15 x 15
  • eMCP 162/186: 11.5 x 13, 10 x 11, 9 x 11, 14 x 18, 12 x 18, 12 x 16, 15 x 15
  • eMCP 221: 11.5 x 13, 10 x 11, 9 x 11, 14 x 18, 12 x 18, 12 x 16, 15 x 15
  • eMCP 529: 11.5 x 13, 10 x 11, 9 x 11, 14 x 18, 12 x 18, 12 x 16, 15 x 15



Form factor: External device (153,50х84х40 mm)

Interface type: USB3.0

Diagnostic ports: 2 х USB 3.0 (HUB), 1 x USB 3.0 (Adapter), Port eMMC (SD/eMMC/eMCP), Port SD/microSD (SD/eMMC/eMCP/microSD)

Power adapter: 4-channel independent power adapter with protection from overvoltage

Operating temperature range: 0-40°C.

Power Supply: External AC / DC 19 V

Number of active licenses: 2 (to install the software on both a desktop computer and a laptop)

Other: write protect switchers for SD / MMC Ports

PC-3000 Mobile

RECOMMENDED SYSTEM REQUIREMENTS:

CPU: Intel Core i5 (4 cores, 4 threads) or AMD Ryzen 5;

RAM: 8 Gb;

Available disk space: 200 MB of available disk space (for installation of software)

Operating system: Windows 7 (SP1), 8, 8.1, 10, x86, x64

Display: Widescreen Full HD 1920×1080

Ports: USB 3.0 Type-A port for connection of PC-3000 Mobile (an Intel xHCI HOST controller is recommended)

PC-3000 Mobile

SUPPORTED DEVICES:



MMC memory chips

(for old smartphones without encryption)

Types: eMMC 153/169, eMCP 162/186, eMCP 221, eMCP 529

Sizes: 11,5×13, 10×11, 9×11, 14×18, 12×18, 12×16, 15×15



Processors models

Access type for modern Android-based devices with FDE and PFE encryption without chip-off



  • Mediatek-based
  • Qualcomm-based
  • Spreadtrum/UNISOC



If the PC-3000 Mobile PRO does not support your mobile device but your device is based on the supported controller, please contact our Technical Support through the New TS Portal ts.acelab.eu.com or via email ts@acelab.eu.com with your request, and our developers will do their best to add your device to the support list in the nearest time.



Updates



The PC-3000 Mobile gets regular software updates. Our developers constantly work on the enhancements and add the support of new mobile devices. You can download the latest software versions on the New TS Portal ts.acelab.eu.com.



If the PC-3000 Mobile PRO does not support your mobile device but your device is based on the supported controller, please contact our Technical Support through the New TS Portal or via email ts@acelab.eu.com with your request, and our developers will do their best to add your device to the support list in the nearest time.



DELIVERY KIT

PC-3000 Mobile

  • PC-3000 Mobile PRO controller – 1 pc.
  • PC-3000 Mobile power supply unit – 1 pc.
  • SD/MMC adapter + 7 size
  • Constraint frames – 1 pc.
  • USB 3.0 – USB Type-C adapter – 1 pc.
  • MicroUSB – USB Type-C adapter – 1 pc.
  • USB 3.0 cable – 1 pc.
  • USB-USB Type С cable – 1 pc.
  • USB-micro USB cable – 1 pc.
  • Universal download сable – 1 pc.
  • PC-3000 Mobile PRO software – 1 pc.
  • User manual – 1 book
  • Equipment hard case – 1 pc.
